Cnlinko LP20 4 Pin Wire Connector
LP20 4pin Waterproof Aviation M20 Fais Fab Connector txais cov kua dej dynamic tsim, thiab cov khoom siv ib lub khawm yog nias thiab hloov ceev ceev los tiv thaiv cov ntaub ntawv tsis ua hauj lwm los ntawm kev ua haujlwm tsis raug ntawm kev siv thaum kawg, uas ua rau muaj txiaj ntsig zoo lub neej ntawm cov khoom. LP Series cov khoom siv hluav taws xob thiab cov teeb liab yog siv ib leeg lossis ua ke los muab kev daws teeb meem rau kev sib txuas ntawm ntau qhov kev lag luam. Xws li: cov khoom siv audio-visual, cov cuab yeej kho mob, kev tswj hwm kev lag luam, cov cuab yeej tshawb nrhiav thiab ntsuas, AV systems, xov tooj cua thiab TV thiab kev lag luam kev sib txuas lus.
Hauj lwm lawm
Lub koom haum Cnlinko 4 Pin Wire Connector LP20
1.Product Introduction
Peb yog cov cuab yeej siv hauv kev tsim khoom, xa tawm thiab muab rau peb cov neeg siv khoom muaj txiaj ntsig zoo heev LP20 4-pin Waterproof Aviation M20 Power Connector Series Waterproof Connector uas muaj nyob rau hauv qab no specification.
LP20 4-pin Waterproof Aviation M20 Fais Fab Connector txais cov kua dej dynamic tsim, thiab cov khoom siv ib lub khawm yog nias thiab hloov ceev ceev los tiv thaiv cov ntaub ntawv tsis ua hauj lwm los ntawm kev ua haujlwm tsis raug ntawm kev siv thaum kawg, uas ua rau muaj txiaj ntsig zoo lub neej ntawm cov khoom. LP Series cov khoom siv hluav taws xob thiab cov teeb liab yog siv ib leeg lossis ua ke los muab kev daws teeb meem rau kev sib txuas ntawm ntau qhov kev lag luam. Xws li: cov khoom siv audio-visual, cov cuab yeej kho mob, kev tswj hwm kev lag luam, cov cuab yeej tshawb nrhiav thiab ntsuas, AV systems, xov tooj cua thiab TV thiab kev lag luam kev sib txuas lus.
2.Product Specification
LP20 4-pin Waterproof Aviation M20 Power Connector rau kev siv fais fab. Haum rau 26-24 AWG cable. Rated rau 400V thiab 5 A. Nws xauv rau hauv cov txiv neej cable ntsaws thiab tuaj yeem tso tau yooj yim. Zoo meej rau cov ntawv thov xws li cov khoom siv suab / pom, cov cuab yeej kho mob, cov cuab yeej ntsuas thiab ntsuas, thiab kev tswj hwm kev lag luam.
| Dimensions (tsis muaj Cap) | 28.7mm Qhov siab x 31.4mm Dav (1.13" x 1.24") |
| Hlau Gauge | 26-24 AWG |
| Txoj kab uas hla | 5. 5-7 mm |
| Tiv tauj Diameter | 1 hli |
| Rated Tam sim no | 5 amp ua |
| Kev khiav hauj lwm voltage | 400V |
| Tiv tauj Resistance | <5 mΩ |
| Withstanding voltage | 1500V |
| Rwb thaiv tsev Resistance | > 500 mΩ |
| Kev tiv thaiv Ingress | IP65/67 |
| Ua haujlwm kub | -40 C rau 80 C (-40 F txog 176 F) |
| Kev ua neej nyob | 1700 Cycle |
| Khoom siv tsev | Zinc Alloy |
| Cov ntaub ntawv tiv tauj | Kub Plated Copper Alloy |
| Flammability Rating | UL{0}}V0 |
3.FAQ
Q: Lub sijhawm khoom xa tuaj yog dab tsi?
A: Feem ntau nws yuav siv li 15 hnub ua haujlwm los tsim ib qho kev txiav txim los ntawm MOQ rau 40HQ thawv. Tab sis lub sij hawm xa tuaj tiag tiag yuav txawv rau kev txiav txim sib txawv lossis lub sijhawm sib txawv.
Q: Kuv puas tuaj yeem sib xyaw cov qauv sib txawv hauv ib lub thawv?
A: Yog, cov qauv sib txawv tuaj yeem sib xyaw hauv ib lub thawv, tab sis qhov ntau ntawm txhua tus qauv yuav tsum tsis txhob tsawg dua MOQ.
Q: Koj lub Hoobkas ua li cas txog kev tswj kom zoo?
A: Qhov zoo yog qhov tseem ceeb. Sparklewheel Cov neeg ib txwm muab qhov tseem ceeb rau kev tswj xyuas zoo txij thaum pib mus txog thaum kawg ntawm kev tsim khoom. Txhua yam khoom yuav raug sib sau ua ke thiab ua tib zoo kuaj ua ntej nws tau ntim rau cov khoom xa tuaj.
4. Daim ntawv pov thawj
5. Ntim & Shipping
